Dual 1-of-4 Line Data Selector/Multiplexer IC – 74HC153

Description:

Dual 1-of-4 Line Data Selector/Multiplexer IC - 74HC153

The 74HC Series74HC153 IC's data selectors/multiplexers contains inverters and drivers to supply fully complementary, on-chip, binary decoding data selection to the AND-OR-invert gates. Separate strobe inputs are provided for each of the two four-line sections.

The 74HC153 features independent enable inputs (nE) and common data select inputs (S0 and S1). For each multiplexer, the select inputs select one of the four binary inputs and routes it to the multiplexer output (nY). A HIGH onEforces the corresponding multiplexer outputs LOW. Inputs include clamp diodes

Pinout:

Pinout Of74HC153 IC
